MODEL NO.

83X10

TV  SYSTEM

NTSC

PAL

IMAGE  SENSOR

1/3-inch  CCD  Image  Sensor

CCD TOTAL PIXELS

542 (H) x 496 (V)

542 (H) x 586(V)

SCANNING SYSTEM

525 lines, 60 fields/sec

625 lines, 50 fields/sec

SYNC SYSTEM

Internal

MINIMUM  ILLUMINATION

0.3 Lux  F1.2  5600ºK

LENS & VIEW ANGLE

3.6mm  F2.0  /  92°

RESOLUTION

400 TVL / 470 TVL (Enhanced)

S / N  RATIO

52dB (MIN) / 60dB (TYP)  (AGC OFF)

WHITE BALANCE

ATW / AWC / FIX  Switchable  ( Zero color rolling)

WHITE BALANCE RANGE

 3200---10000 ºK

AUTO IRIS

A.E.S.

ELECTRONIC  SHUTTER

1/60~1/120,000 sec.

1/50~1/120,000 sec.

VIDEO OUTPUT

1.0V p-p composite video at 75 ohm

GAMMA CORRECTION

0.45

MIRROR FUNCTION

Optional

DIGITAL ZOOM ( 2X )

Optional

GAIN  CONTROL

AGC

OPERATION TEMPERATURE

-20℃ TO  50℃

OPERATIONAL  HUMIDITY

within 85﹪RH

POWER  SUPPLY

DC12V / 90mA
